TECHNICAL DESIGN OF MINE DRAINAGE SYSTEM IN LIMESTONE MINING AT UP. PARNO, KARANGASEM VILLAGE, PONJONG DISTRICT, GUNUNGKIDUL DISTRICT, REGION YOGYAKARTA SPECIAL
RANCANGAN TEKNIS SISTEM PENYALIRAN TAMBANG PADA PENAMBANGAN BATUGAMPING DI UP. PARNO, DESA KARANGASEM, KECAMATAN PONJONG, KABUPATEN GUNUNGKIDUL, DAERAH ISTIMEWA YOGYAKARTA
Keywords:
Rainfall analysis,, rain catchment area, open channel, settling pondAbstract
UP. Parno is a limestone mining company operating in Karangasem Village, Ponjong District, Gunungkidul Regency. UP. Parno has an IUP with an area of 5.7 hectares by implementing an open mining system (surface mining) with the quarry method. Surface mining affects the surface due to climate. When it rains, the falling rainwater can pool in the mining area and around the lower mining openings. If it is dry, no rainwater enters the mining area. Thus, an adequate mine drainage system design is needed. Water discharge is the main thing to determine a good mine drainage system design. Based on the results of the calculation of rainfall data from 2011 to 2020, it is known that the planned rainfall is 101.70 mm/day, and the rainfall intensity is 43.77 mm/hour with a five-year return period of rain. The purpose of making an open channel is to drain rainwater that enters the mining area and drain runoff so that the mine road does not stagnate. The designed open channel has dimensions of b = 1.50 m; B = 1.00 m; d = 0.60 m; h = 0.50 m; a = 0.60 m. Culverts function to drain water from open channels that cut off haul roads. The culverts required are made of smooth cement surface, with a diameter of 0.35 m. The water flowing by the open channel will go to the settling pond to be purified first before flowing into the river around the mining area. The settling pond is designed to consist of three compartments with an area of 264 m2 each and 666 m3 volume. Dredging of sediment in settling ponds must be carried out every 10 months and 13 days.
Downloads
References
Bemmelen, R. W. Van. (1948). The Geology of Indonesia Vol IA General Geology of Indonesia and Adjacent Archipelagoes. Batavia: The Hague 1949.
Chay Asdak, 1995, Hidrologi dan Pengelolaan Daerah Aliran Sungai, Gadjah Mada University Press, P.O.Box 14 Bulaksumur Yogyakarta, hal. 53-78.
Partanto Prodjosumarto, 1994. Rancangan Kolam Pengendapan sebagai Pelengkap Sistem Penirisan Tambang, Jurusan Teknik Pertambangan Institut Teknologi Bandung.
Powers, J. Patrick, 1992, Construction Dewatering: New Methods and Applications, Jhon Wiley and Sons, New York, hal 177-188; 253-256. Read, John & Stacey, Peter. 2009. Guidelines for Open Pit Slope Design. Australia: CSIRO Publishing.
Rudy S. Gautama, 2019, Sistem Penyaliran Tambang, Institut Teknologi Bandung, hal. 2-3; 4-3; 5-10.
Shapefile Nasional Badan Informasi Geospasial. (2018). (Pusat Pengelolaan dan Penyebarluasan Informasi Geospasial) Diakses pada Oktober 2021, dari Peta RBI Format shp: https://tanahair.indonesia.go.id/portal-web.
Soedibyo. 2003. Teknik Bendungan. Pradnya Paramita, Jakarta.
Soemarto, C.D., 1987. Hidrologi Teknik. Usaha Nasional, Surabaya.
Sosrodarsono S. dan Takeda K. 1987. Hidrologi untuk Pengairan. Jalan Kebon Sirih No. 46 Jakarta: PT. Pradnya Paramita, hal. 2-8.
Suripin, 2004, Sistem Drainase Perkotaan yang Berkelanjutan, Jalan Beo 38- 40 Yogyakarta: PT. Andi Offset, hal. 20 – 21; 50 – 53; 67-68; 77; 79-82; 144- 151.
Surono, 2008, Jurnal Geologi Indonesia, Vol, 3 No, 4 Desember 2008: Litostratigrafi dan sedimentasi Formasi Kebo dan Formasi Butak di Pegunungan Baturagung, Jawa Tengah Bagian Selatan, Bandung: Pusat Survei Geologi, Hal 185.
Surono, 2008, Sedimentasi Formasi Semilir di Desa Sendang, Wuryantor, Wonogiri, Indonesia, Bandung: Pusat Survei Geologi, Hal 33.
Usaha Pertambangan Parno, 2017, Laporan Studi Kelayakan Usaha Pertambangan Parno, Gunung Kidul, Daerah Istimewa Yogyakarta. Hal 2-6.
Tang, Yiqun. 2015. Groundwater Engineering. Singapore: Springer Environmental Science and Engineering.
